TRACTION ROBOT

MODEL No. F 405.15.S TRACTION ROBOT (MADE IN ITALY)

Pulling robot made of light alloy, movement controlled by two electric motors
that drive two aluminium wheels lined with Vulkollan. The motor is powered by
an interchangeable and rechargeable battery. Can be locked and unlocked and recovered in case of emergency
stop. Complete radio control for controlling the movement. The robot can be used on any rope/conductor. The
lower wheels allow it to overpass little obstacles, like conductor joints.

RADIO-CONTROL
Radio control with forward/backward and stop control keys, max distance 400m (maximum capacity reached
in ideal weather conditions). Complete with receiving unit, battery charger and 2 removable and rechargeable
batteries. Protection IP67.
OPTIONAL

• Battery-charger for the battery of the motors, complete with 230VAC transformer. F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
• Supplied in metal box (1.00 x 0.60 x 0.90m).

SPECIFICATIONS

PERFORMANCES
Max pull force 1 kN
Max inclination 15°
Max pull speed 20 m/min
Min. pull speed 15 m/min

FEATURES
Wheels diameter (external) 190 mm
Wheels diameter (internal) 140mm
Wheels groove width 55 mm
Dimensions 0.8 x 0.5 x 0.7 m
Weight 40 kg

MOTORS FOR THE MOVEMENT
Feeding Electric
Power (each motor) 0.15 kW
Electric plant 12 V www.specialisedforce.com.au
