STRINGING MACHINERY –
OVERHEAD

OVERHEAD STRINGING MACHINERY (MADE IN ITALY)

Suitable for overhead stringing applications in the electrical utility
F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
(Transmission and distribution lines, etc) and associated industry such
as telecommunications and railway. More machines available upon
request. Some features and performances of machines are able to be
modified on request.
Performances of machines listed are without optional devices, at sea level at a SCAN
temperature of 20ºC. Dimensions and weights are shown without optional devices. & PLAY
Information may change without notice due to continual research, development and
improvement. Images and drawings are indicative only.

1 2 3

4 5 6
ENGINE - POWER
REF MODEL TYPE CAPSTAN (ø) MAX ROPE (ø) CAPACITY (kN)
(hp/kw)
1 F265.P.20 Puller 2 x 200mm 8mm Petrol - 18/13 20
2 F280.35 Puller 2 x 325mm 16mm Diesel – 35.2/26 35
3 F235.90 Puller 2 x 450mm 20mm Diesel - 156/115 90
4 F260.150.22 Puller 4 x 600mm 2 x 16mm Diesel - 278/205 150 (2 x 75)
www.specialisedforce.com.au
5 F120.AF.75.2 Puller/Tensioner 2 x 1500mm 2 x 42mm Diesel - 105/77 75
6 F120.75.2 Tensioner 2 x 1500mm 2 x 42mm Diesel - 60/44 75
TECHNICAL

MODEL F265.P.20 F280.35 F235.90 F260.150.22 F120.AF.75.2 F120.75.2
ENGINE 1 2 3 4 5 6
Electronic Start 12V Battery     
Electronic Start 24V Battery P
Air Cooled 
Water     
PULL PERFORMANCE
Max Pull (kN) 20 35 90 1 x 50-2 x 75 75
Max/Min Tension Force (kN) 75/4
Speed at Max Pull 18m/min 20m/min 41m/min 43m/min 33m/min 16m/min
Max Speed 65m/min 66m/min 91m/min 76m/min 83m/min 83m/min
Pull at Max Speed (kN) 3.5 13 40 1 x 90-2 x 45 35 20
REEL
Type-Extractable Self-Loading     (Double)
DIMENSIONS & WEIGHT
Length x Width x Height (m) 2.1 x 1.5 x 1.2 2.15 x 1.60 x 1.55 3.7 x 2.15 x 2.1 4.6 x 2.45 x 2.75 4.0 x 2.1 x 2.4 3.8 x 2.05 x 2.4
Weight (kg) W/O Rope 535 1700 3900 8500 4500 3500
All Machines are available with an array options (some outlined below) e.g. Cable(10m) – Radio(100m) remote control, Hyd stabilisers etc.
Please contact your nearest Specialised Force Branch or visit our website www.specialisedforce.com.au for a full spec sheet.
PULLERS ARE AVAILABLE UP TO 300kN
PULLER/TENSIONERS ARE AVAILABLE UP TO 180kN
TENSIONERS ARE AVAILABLE UP TO 280kN
