ACCESSORIES – MACHINE

DIGITAL BUILT-IN DATA READ-OUT

F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT

Electronic Instrument for monitoring the working values. Fit for OMAC pullers, tensioners
and puller-tensioners. A must-have device installed on all OMAC machines as a standard.

Model No. DEG

• Large Screen allowing for excellent visibility from any angle
• Graphic, colour display
• Integrated into the main control panel
Features • High capacity memory: Over 200km of line
• High accuracy and reliability due to load cells and encoder system
• Equipped with USB port
• Ease of use
• Reads & displays pull force, speed & length of cable in real time
• Max pull force setting
• Display of working hours
Functions
• Data recording
• Data storage on a pen-drive
• Software provided allows for handling the data stored
Optional

• Portable printer c/w connection cable to be plugged into the machine
• Fit for printing the recorded data directly on the job-site
• Supplied in aluminium case

Model No. 069.5

REMOTE CONTROLS
www.specialisedforce.com.au

Model No. REC.1 REC.2 RER.1
Remote radio-control fit for single
circuit machines. Max operative
Remote circuit by cable. Fit for distance: up to 100m.
“puller” machines with 1 hydraulic The radio control is complete with:
circuit.
Compact remote control by cable. Fit for The control is complete with: • Mini joystick for controlling the
“puller” machines with 1 hydraulic circuit. rotation of the capstans
Description Pull/release buttons and emergency stop • Mini joystick for controlling the • Speed-adjustment control
rotation of the capstans
button. 10m of connection cable. • Speed-adjustment control • Emergency stop button
• Emergency stop button • Back-up cable for connecting the
control to the machine in case of
• 10m of the connection cable emergency

1. Dynamometer to read the 1. Dynamometer to read the
pulling force, meter counter & pulling force, meter counter &
Optional Devices - speedometer speedometer
2. Engine start/stop 2. Engine start/stop
3. Engine accelerator 3. Engine accelerator
