PULLING EYES –
REUSABLE & CRIMP

PULLING EYES

Australian Made
Pulling Eyes

Many sizes and types available, suitable for: Cu & Al (Telecomm/Utility); Stranded Cu/Al wires in all
sizes; Single Core, 3 Core; XLPE Insulated (HV & LV); Gel-filled (Telecommunication) cables, Fibre
Optic and Pressurised Cables.

CEC Type (without spike for single core) CGP5 Type RPE Type
CHE Type (with spike for multi core) (with gel port, for gel filled) (re-usable type with optional sleeve)

CRIMPING KIT

Standard Hand Kit includes; E UNDERGROUND PULLING
• Rope Crimping Block & Retaining Ring (CDB-100 [<120) or CDB-150 [>120)
and CRR-120 for CDB-100, CRR-150 for CDB-150
• Hydraulic Ram Cylinder (RG-106)
• Hydraulic Hose with Couplers & Dust Caps (HPS-0602CB)
• Hydraulic Hand Pump with Gauge (P-235, FGA-1 & PG-63)
Additional Required Items;
• Push Rod, 1 Required for each Crimp Die* (CDBPR)
* NOTE – Crimper Dies and Crimper ropes Sold Separately in Size Ranges
(Electric pump kit with pendant hand control or foot switch also available upon request)

RE-USABLE PULLING EYES

Model No. Core Core Size (mm) OD
RPE-1015 Single 10-15
RPE-1520 Single 15-20
RPE-2025 Single 20-25
RPE-2530 Single 25-30
RPE-3035 Single 30-35
RPE-3540 Single 35-40
RPE-4045 Single 40-45
RPE-4550 Single 45-55
SINGLE CORE MULTIPLE CORE RPE-5055 Single 50-55
RPE-5560 Single 55-60 www.specialisedforce.com.au
RPE-6065 Single 60-65
Reusable pulling eyes for pulling underground cables. RPE-6570 Single 65-70
Available in single and multiple core versions. RPE3-1015 Triple 10-15
Conical wedge included for pulling single core cables RPE3-1520 Triple 15-20
and have standard sleeve lengths which are a RPE3-2025 Triple 20-25
maximum of 300mm ID. RPE3-2530 Triple 25-30

RPE3-3035 Triple 30-35
RPE4-1015 Quad 10-15
RPE4-1520 Quad 15-20
RPE4-2025 Quad 20-25
RPE4-2530 Quad 25-30
RPE4-3035 Quad 30-35
Custom sizes available.
