POWER CABLE –
DIMENSIONAL DATA
POWER CABLE DIMENSIONAL DATA
REFERENCES TABLES
DIMENSIONAL DATA DIE SIZE A/F (mm) Cable Types
Imperial Insulated XLPE /
Cross Stranding OD of Equivalent AWG Size PVC Sheathed PVC Multiple Core Cables (0.6/1kV) XLPE / URD Name
Sectional (No / Wire Conductor (No/Wire (American Cu Die Al Die
Area Diameter (mm) Diameter Wire (A/F) (A/F) • • • • • • • • • • • • • • • • • • Cores
(mm2) Ø mm) Gauge) Earth
Ø)
www.specialisedforce.com.au
1/1.13 1.1
1 1/.044 18 - - 3.0 4.0 - 10.0 - - -
7/0.40 1.2
1/1.3 1.4 3/.029
1.5 16 - - 3.5 4.5 - 11.5 8.5 7.5 10.5
7/0.50 1.5 1/.064
2.0 3/.036
2.5 7/0.67 14 - - 4.0 5.0 - 12.0 8.0 11.5 12.5
2.0 7/.029
4 7/0.85 2.6 7/.036 12 - - 4.5 6.0 - 13.5 11.5 15.5 19.0
6 7/1.04 3.1 7/.044 9 4.4 9.0 5.5 7.0 - 14.5 12.5 16.5 15.0
10 7/1.35 4.1 7/.052 7 5.7 9.0 6.0 8.0 - 17.0 17.0 18.5 20.0 Stranded Conductor
7/.064 Solid Conductor
16 7/1.70 5.1 5 6.3 9.0 7.0 9.0 9.5 19.0 19.0 20.5 23.0
19/.044
25 19/1.35 6.8 19/.052 3 7.7 9.0 8.5 11.0 10.5 23.0 22.0 24.0 26.5
35 19/1.53 7.7 19/.064 2 9.2 9.0 9.5 12.0 11.5 - 25.0 26.5 29.5 Approx
50 19/1.7 8.9 19/.072 1/0 10.4 13.2 11.0 14.0 13.0 - 28.0 31.0 35.0 OD of
70 19/2.14 10.7 19/.083 2/0 11.5 13.2 12.5 15.5 15.0 - 32.0 35.0 39.0 Cable
95 37/1.7 12.5 37/.072 3/0 14.2 17.3 15.5 18.0 17.5 - - 40.0 45.0
120 37/2.03 14.2 37/.083 250MCM 16.5 17.3 17.5 20.5 20.0 - - 43.5 50.0
150 37/2.25 15.8 37/.093 300MCM 18.3 22.0 19.0 24.5 21.5 - - 48.5 55.0
185 37/2.52 17.6 37/.103 350MCM 20.0 22.0 21.5 26.5 23.5 - - 54.0 61.0 43.0 47.5
240 61/2.25 20.3 61/.093 500MCM 23.1 28.4 24.5 28.0 26.5 - - 61.0 69.5 50.0 53.5
300 61/2.52 22.3 61/.103 600MCM 26.0 28.4 27.0 31.0 29.5 - - 68.0 77.0
400 61/2.85 25.7 91/.093 800MCM 28.1 39.0 31.0 35.0 33.5 - - - -
91/.103
500 61/3.20 28.8 1000MCM 31.0 39.0 34.5 38.5 37.0 - - - -
127/.093
630 127/2.52 32.8 127/.103 1200MCM 37.0 43.2 38.0 42.5 41.5 - - - -
800 127/2.85 37.0 127/.112 - 43.2 52.5 - - - - - - -
1,000 127/3.7 41.6 127/.125 - 48.0 52.5 - - - - - - -
Based on stranded copper cable dimensional data
