WIRE ROPE – ANTI TWIST

ANTI-TWISTING STEEL ROPE

Model Number 21.12
Anti-twisting galvanised steel rope specifically designed for stringing operations. Made up of 12 braided strands. High
Description resistant to break, anti-twisting, flexible, safe and easy to handle. The linear contact between the braided strands grants a
low stress on the rope. Supplied wound up on steel or wooden reels.

Model No. Nominal Diameter (mm) Breaking Load (kN) Weight (kg) Standard Lengths* (m)
21.12.08 8 44 0.22 1000
21.12.10 10 72 0.35 1000
21.12.13 13 105 0.55 1000 E UNDERGROUND PULLING
21.12.16 16 163 0.80 1000
21.12.18 18 235 1.07 1000
21.12.20 20 268 1.24 1000
21.12.22 22 330 1.56 900
21.12.24 24 380 1.80 800
21.12.28 28 480 2.80 600
*Other Ropes and Lengths available - Please contact your nearest Specialised Force Branch for further information www.specialisedforce.com.au

Model No. Description Optional Devices

• Total galvanization.
Welded and painted
F162 steel reel, complete with • Additional pair of standard dials.
central dials and bolts. • Pair of dials equipped with ball
bearings.

Welded and painted • Total galvanization.
steel conical reel with
F164 openable side. Complete • Additional pair of standard dials.
with central dials and • Pair of dials equipped with ball
bolts. bearings.

STEEL REELS FOR ROPES

Weight Without
Model No. Dimensions (mm)
Rope (kg) www.specialisedforce.com.au
A B C D E F
F162.060 700 530 460 219 50 27
F162.110 1100 560 460 570 420 50 66
F162.140 1400 560 460 570 420 50 105
F162.160 1600 560 460 570 420 50 120
F162.190 1900 560 460 570 420 50 140
F162.200 2200 1560 1400 1010 420 100 950
F164.060 700 530 460 219 50 40
F164.110 1100 560 460 570 420 50 85
F164.140 1400 560 460 570 420 50 115
F164.160 1600 560 460 570 420 50 130
F164.190 1900 560 460 570 420 50 220
F164.205 2050 1310 1170 630 420 50 550
F164.220 2200 1310 1170 1010 420 100 1050
