ROLLER & SHEAVES – HOOK

HOOK SHEAVES 35.8kN WLL (MADE IN USA)

• Can be used with Greenlee.
• Strong, welded steel frames.
• Forged steel closure type hooks with 25.4mm opening.
• Sheaves are aluminium alloy with self-lubricating bearings.

Greenlee 00872
Model No. OD (mm) Inside Radius (mm) Width (mm) Weight (kg) WLL (kN)
Model No.
E UNDERGROUND PULLING
00872 8012 305 98 127 12.7 35.8
00873 8018 458 178 152 19.9 35.8
00874 8024 610 251 165 30.3 35.8

SPARE PARTS
Sheave Model No. 00872 00873 00874 00873
Diameter (mm) 305 458 610
Description of Part Model No.. Model No. Model No.
Roll Pin 50700 50700 50700
Sheave Pin 00838 00846 00850
Sheave Pin Clip 50302 50302 50302 50302 00874
Sheave Unit 00843 00844 00845
Yoke Frame 00854 00855 00856

THESE SHEAVES IDEAL FOR WORKING WITH GREENLEE ELECTRIC CABLE PULLERS. USE ROLLER
SUITABLE FOR MACHINE CAPACITY, REFER PAGE 136

HOOK SHEAVES (MADE IN USA)
• Strong, welded steel frames.
• Forged steel closure-type hooks with 25.4mm opening.
• 127mm wide aluminium alloy sheaves with self-lubricating bearings.

Greenlee Inside Radius Sheave Width
www.specialisedforce.com.au
Model No. OD (mm) Weight (kg) WLL (kN)
Model No. (mm) (mm)
15324 650 152 38 127 4.0 17.8
15325 651 305 84 127 6.8 17.8 15324
15326 652 457 178 127 11.3 17.8
15327 653 610 249 127 15.9 17.8
SPARE PARTS

Sheave Model No. 15324 15325 15326 15327
Diameter (mm) 152 305 457 610
Description of Part Model No. Model No. Model No. Model No.
Sheave Pin 16797 16797 16797 16797
Sheave Pin Clip (2) 50302 50302 50302 50302
Sheave 15362 15358 15363 15364
Sheave Bushing (2) 16798 16798 16798 16798
Yoke Frame 16799 16800 16801 16802 15327
