Page 144 - SF ELEC CAT_V4.0_WEB_F2-UPDATE-18-02-19

WINCH – DUAL CAPSTAN,
PETROL/DIESEL

PORTABLE WINCH-PETROL/DIESEL

D WINCHES

PETROL WINCH DIESEL WINCH
Model No. “GOODWINCH” MODEL No. “GOODWINCH-DIESEL”

Also available without rope clutches
www.specialisedforce.com.au
Model No. GOODWINCH-1
FEATURES
• Safe, infinitely controllable pulling, holding, and lowering with the Goodwinch Portable Petrol or Diesel Twin
Capstan Winch.
• Variable speed from hold, through creep to a full speed of approx. 25m/min (petrol) & 21m/min (diesel).
• Ideal for pulling cables through ducts, raising portable buildings, clearing debris from rivers, lakes and canals,
forestry work, and general rope rescue work, etc.
• Work from either side or run two ropes together to halve the load.
• Two rope clutches (not shown) are included as standard on both models and are used for load holding during
lowering or raising loads on transmission towers and similar structures.
• High quality engineering and design. Reliable, easy to start Honda (4 kW) engine (or Yanmar (3.5 kW) diesel
engine) with a centrifugal gearbox driving the main capstan gearbox and aluminium bollards through a flexible
coupling.
• Aluminium frame, two man lift, removable handles for easy storage.

PROUDLY MARKETED, SERVICED SCAN

& SUPPORTED AUSTRALIA WIDE & PLAY

134 SYDNEY Head Office (02) 9547 1844 Adelaide (08) 8352 8866 Brisbane (07) 3256 6011 Townsville (07) 4728 8756
Darwin (08) 8984 4453 Melbourne (03) 9761 4199 Perth (08) 9354 8544 Port Hedland (08) 9172 1113 Tasmania 0427 423 217
