PUMPS – SUBMERSIBLE

SUBMERSIBLE PUMPS (MADE IN USA)

Compact Submersible Submersible Water
Pump Pump Submersible Trash Pump Submersible Trash Pump

Model No.42191/FF Model No.42190/FF Model No.49334/FF Model No.42192/FF C HYDRAULIC TOOLS & ACCESSORIES
• Self-priming, compact, • High impact strainer • Compact, under 300 mm diameter to • No clog, self-priming, abrasion
lightweight design with housing with easily fit into small areas. resistant impeller pump.
carrying handle. carrying handle. • Self-priming submersible pump can be • Up to 3,407 lpm.
• High impact strainer • Self-priming. placed and operated quickly. • Replaceable wear plates, carry
housing. • Up to 1,514 lpm. • Passes up to 76 mm solids minimising handle and can be run dry without
• Up to 1,041 lpm. • Can be run dry pump blockage from debris. damage.
• Can draw water down to without damage. • Can be run dry without damage for • 101.6 mm NPT discharge – will pass
depth of 45 mm. • Can draw water longer working life. 76 mm solids.
• Can run dry without down to depth of 51 • Carry handle with lifting eye makes it • Locking coupler for discharge hose
damage. mm. easy to transport, move, lift, and lower. included.
• Locking coupler for discharge hose • Can draw water down to depth of
included. 83 mm.
• Can draw water down to depth of 70 mm.
Refer to accessories (below) for hoses and couplings
SPECIFICATIONS

Style Compact Water Trash Trash
Model No. 42191/FF 42190/FF 49334/FF 42192/FF
Included Accessories Flush Face Couplers Flush Face Couplers Flush Face Couplers Flush Face Couplers
System Open- and Closed-Centre Open- and Closed-Centre Open- and Closed-Centre Open- and Closed-Centre
Up to 1,041 lpm at 3m Up to 1,514 lpm at 4.5m Up to 1,893 lpm at 4.5m Up to 3,300 lpm at 3m
Capacity
head height head height head height head height
Intake Port (mm) 49 38 80 102
Discharge Port (mm) 44mm NPT Female 64mm NPT Female 76.2mm NPT Female 102mm
Strainer 67x43mm – 9.5mm 178x64 - -
Openings
Weight (kg) 4.0 10.6 11.7 26.7
Height (mm) 318mm Over Handle 406 Over Handle 360 Over Handle 400
Width (mm) 190 Diameter 305 Diameter 301 Diameter 368 Diameter
Flow Range (lpm) 19-30 15-30 26.5-37.9 19-34 www.specialisedforce.com.au
Operating Pressure (Bar) 0-138 0-138 0-138 0-138
Pressure Port Thread 9/16-18 SAE O-Ring ½” Male NPTF ½” Male NPTF ½” Male NPTF
Return Port Thread ¾-16 SAE O-Ring ½” Male NPTF ½” Male NPTF ½” Male NPTF
ACCESSORIES


Model No. 41220 42104 41219 42105 49499 41189
Suits 42191/FF 42191/FF 42190/FF 42190/FF 49334/FF 42192/FF
Discharge Hose Cam-Lock Coupling Discharge Hose Cam-Lock Coupling Discharge Hose Discharge Hose
Description Assembly for Discharge Hose Assembly for Discharge Hose Assembly Assembly
51mm (2”) x 7.62m 51mm 63.5mm x 7.62m 63.5mm 76mm x 7.62m 102mm x 7.62m
