HOSES & COUPLINGS –
HIGH PRESSURE
“CEJN” HIGH PRESSURE COUPLINGS Flush-Face Coupler
Thread Thread Female Male (Nipple)
Type
A one-hand-to-connect, non-drip coupling “CEJN” HIGH PRESSURE COUPLINGS
Part Number
Part Number
with built-in safety function
The one-hand-to-connect Flat-Face couplings ¼ BSPP FEMALE
have been developed to reliably meet the rigorous PARALLEL 10-116-1219
demands of high pressure hydraulic applications. 10-115-6202
Engineered to exacting tolerances, using the most
durable materials, CEJN high pressure couplings hold ¼ NPT FEMALE
up where other couplings fail. 10-116-1419 10-115-6402
FEATURES
One-hand-to-connect 3/8 NPT FEMALE
The nipple is pushed into the coupling and is locked 10-116-1429 10-115-6404
automatically. The locking sleeve does not need to be C HYDRAULIC TOOLS & ACCESSORIES
manually positioned. MALE
¼ BSPP PARALLEL
Unique automatic safety function eliminates 10-116-1269** 10-115-6212**
accidental disconnection
Turn the locking sleeve 30° and then pull backwards
MALE
to release. The Flat-Face design ensures non-drip 3/8 BSPT TAPERED
Maximum Working Pressure 800Bar 10-116-1279 10-115-6154
3/8 NPT MALE
10-116-1479 10-115-6454
¼ NPT MALE
10-116-1469 10-115-6452
Aluminium Dust Caps
10-115-4101 10-115-4102 10-115-4100
SUITS ALL THE ABOVE NIPPLES
SUITS ALL THE ABOVE NIPPLES SUITS ALL THE ABOVE COUPLERS
WITH PRESSURE ELIMINATOR
**NOTE: USE WITH 19-950-0083 RUBBER/METAL SEAL
HP8-4 HIGH PRESSURE NON-CONDUCTIVE HOSE
HP8-4 High Pressure Non-Conductive Hydraulic hose assemblies are used in many
applications where non-conductivity of hoses is required, including live power line work
and cable spiking. We can supply HP8-4 high pressure hydraulic hose assemblies in any
length required. Hose assemblies are supplied with 3/8” NPT male ends and can be www.specialisedforce.com.au
fitted with any style of couplings required. HP8-4 hose is supplied with an orange outer
jacket cover for easy identification. Hydraulic pressure test certificates can be supplied
at extra cost if required. Meets or exceeds SAE J517 for less than 50 micro-amps of
leakage under 75,000 volts per 300mm.
Jacket Min. ID Max. OD Max. Work Min. Burst Min. Bend Weight
Series
Colour (mm) (mm) Pressure (MPa) Pressure (MPa) Radius (mm) (kg/mm)
HP8-4 Orange 6.0 15.0 69.0 275.9 64 0.16
Refer Page 116 and Above for Couplings
