HOSES – HIGH PRESSURE

HOSE - HIGH PRESSURE

C HYDRAULIC TOOLS & ACCESSORIES

SPECIALISED FORCE OFFER A WIDE RANGE AND LENGTHS OF HIGH & LOW
PRESSURE HYDRAULIC HOSE

Please contact you nearest Specialised Force Branch for further information

OD Working Working
Model No. Brand Type (Size - Id (mm)) Temp Range Weight
(mm) Pressure (Bar) Pressure (Psi)
HPS-06R” Durapac RED ¼ 6.6 12.7 700 10,000 -40° to 100° 180g/m
HPS-06B” Durapac BLACK ¼ 6.6 12.7 700 10,000 -40° to 100° 180g/m
HPS-06T” Durapac Twin RED & BLACK ¼ 6.0 12.7 700 10,000 -40° to 100° 180g/m
Non Conductive “Tested To 75,000 Volts Per 300mm”
www.specialisedforce.com.au
HP8-403-B38NM-CCN* Parker 3m ORANGE 1/4 6.0 15.0 700 10,000 -40° to 100° 160gm
HP8-405-B38NM-CCN* Parker 5m ORANGE 1/4 6.0 15.0 700 10,000 -40° to 100° 160gm
B098 NRP Twin ORANGE 3/8 10.0 19.0 155 2250 -40° to 93° 600g/m
* Fitted with CEJN couplings & dust caps (10-116-1429 & 10-115-6404) suitable for POWAQUIP Model No. BP1108A battery pump
“PARKER” HIGH PRESSURE COUPLINGS

Screw Type Coupler
Thread Type
Female Male
3/8 NPT MALE 3050-3 3010-3

DUST CAP TO SUIT SCREW TYPE COUPLERS 3005-3 3009-3

Also refer next page for additional couplings
