STORAGE EQUIPMENT –
TOOL BAGS & BUCKETS

STORAGE EQUIPMENT (MADE IN USA)

BAGS AND TOOL BUCKETS
All Estex tool buckets are made of heavy duty canvas or vinyl coated
nylon for long wear and use. The top ring is a single piece moulded,
non-metallic material designed to stay open even under severe and
continuous load. The bottoms are made of high impact polymer
resins or leather.
The bag has leather side supports at the rope holes and a unique Estex
feature whereby the bottom is stitched on and the body of the bag is folded
back over the stitches to protect the threads from abrasion and excessive
bucket bottom. Otherwise, your bucket becomes a rough sharp source of LIVE WORKING. STORAGE & LINESMAN ACCESSORIES
wear on the bucket truck and on the aerial bucket.
The bucket also has Strong UV resistance and rot resistant rope handle
Hose Bag
Model No. 2630
Model No. Description Dimensions (mm) Weight (kg)
2630 Hydraulic hose bag, heavy weight vinyl 432 x 89 x 470 1.8

TOOL BUCKETS

NOT RATED LOAD LOAD LOAD LOAD
RATED RATED RATED RATED
10:1 safety 10:1 safety 10:1 safety 10:1 safety H
factor factor factor factor

Miniature Tool Bucket Vinyl Tool Bucket Canvas Tool Bucket Tapered Canvas Tool Bucket Splicers Tool Bucket Model
Model No. 2009 Model No. 2059-V-HB Model No. 2022 Model No. 2050-S-IP No. 2059

Model No. Description Dimensions (mm) Weight (kg)

2009 Miniature tool bucket, without pockets 127 Ø opening x 152 High 0.9
2022 Heavy duty canvas tool bucket, moulded top ring & bottom, 203 Ø opening x 305 High 1.0 www.specialisedforce.com.au
polypropelene handle without pockets WLL 36kg
305 Ø opening
2050-S-IP Tapered heavy duty canvas tool bucket, 203 Ø base x 305 High 1.1
moulded top ring & bottom WLL 36kg
2059-V-HB Vinyl tool bucket with plastic bottom, 14 pockets, 304 Ø opening x 304 High 1.3
rope handle & snaphook 36kg.
Splicers heavy duty canvas tool bucket moulded top ring &
2059 bottom, polypropelene handle, (14 pockets outside). 36kg rated. 305 Ø x 305 High 1.4
