Page 79 - SF ELEC CAT_V4.0_WEB_F2-UPDATE-18-02-19

RATCHET HAND CUTTER –
AL/CU/ACSR

MODEL NO. 9009 – JENNY RATCHET CUTTERS FOR ACSR (MADE IN USA)

ALSO

CUTS

ACSR

B CABLE CUTTING

SHOWN CUTTING ACSR

FEATURES CARE & MAINTENANCE
• Full ratcheting cycle A hand cutter of this design when used
• Release feature in all cutting positions correctly on materials within its cutting
• Handle lock in closed position capacity will give years of trouble-free
• Single Hand Operation operation. It is a precision tool and should be
• Blades made from 6150 alloy steel (Chrome treated as such.
Vanadium) heat treated • Do not drop or hit tool on hard objects as damaged
• Curved handle design for maximum leverage ratchet teeth will not allow the drive pawl to
• Full range of replacement parts available engage correctly.
• Keep the tool free from dirt, mud and foreign
SPECIFICATIONS objects to prevent the ratchet teeth from becoming
clogged and preventing the drive pawl from
Weight (kg) 0.5 engaging correctly.
Length (mm) 266 • Keep working parts clean and lightly oiled.

• Cuts Most ACSR up to 210mm² with ease and
suitable for Galvanised Steel Support Wire 3/
2.5mmØ (Catenary Wire) www.specialisedforce.com.au
• Do not cut Guy Strand Wire PROUDLY MARKETED, SERVICED
• Do not attempt to cut ACSR which contains a single & SUPPORTED AUSTRALIA WIDE
high tensile strand exceeding 3/16” (4.75 mm) Ø or Full range of
multiple steel strands exceeding 2.5mm Ø with 7 or spares available
more strands
• Suitable for RAISIN ACSR with 4 x 2.5mm Ø inner
steel strands.
• Suitable for stranded copper to 185mm2 (18mm Ø)
not larger due to the blunt cutting edge design. SCAN
