Page 314 - SF ELEC CAT_V4.0_WEB_F2-UPDATE-18-02-19

WARNING MARKERS, LV
GUARDS & HOSES

GUY GUARDS

LIVE WORKING. STORAGE & LINESMAN ACCESSORIES
Image Model No. Description Dimensions Certification
For Stay & Guy Wires
GG (Not Rated For Electrical 2m x 45mm HDPE
Insulation)
JUMPER WIRE GUARDS

Image Model No. Description Class Working Voltage (VAC) Dimensions Certification

IPEP Flexible hose for covering Bonds, I 650 10m x 35mm AS4202
Bridges & Jumper Wires

PANTHER TAILS

Image Model No. Description Class Working Voltage (VAC) Dimensions Certification
TPP20 3m x 20mm
2 15kV AS4202 – HDPE
TPP35 Unique 2 tone 3m x 35mm
design
TPP15* 2 15kV 60m x 15mm ROLL AS4202 EVA

TPLBL Label 2 15kV AS4202

*Installation tool (TPP15-TL) available upon request
WM SERIES LINE WARNING MARKERS & FLAGS
H

3D Eye Ring R/W 3D Eye Ring B/W 3D Eye Ring B/Y Flag Eye Ring Orange
WM-CS-E-1D-RW WM-CS-E-1D-CP WM-CS-E-1D-BY WM-CS-E-1B-O
www.specialisedforce.com.au

Mini 3D Eye Ring R/W Mini 3D Eye Ring B/W Mini 3D Eye Ring B/Y
WM-CS-E-1E-RW WM-CS-E-1E-BW WM-CS-E-1E-BY
FEATURES
• Aerodynamic design, rotates for high impact visibility • Premium High – Vis Reflectors
• Anti-creep Clamp design • Eye Ring fitting
• Installed with standard Live Line Tools • Customised flags or marker options
• UV stabilised and tough non-conductive plastics available. Universal clamp fits all lines
• Latest technology articulated 3D design from 2 - 50mm diameter
All Rights Reserved Patent Pending

Model No. Product Type Line Attachment Hot Stick Attachment Style of Warning Device Colour
WM-CS-E-1D-RW Warning Marker Clam Shell Eye Ring 3D Red/White
WM-CS-E-1D-BW Warning Marker Clam Shell Eye Ring 3D Black/White
WM-CS-E-1D-BY Warning Marker Clam Shell Eye Ring 3D Black/Yellow
WM-CS-E-1B-O Warning Marker Clam Shell Eye Ring Flag Orange
WM-CS-E-1E-RW Mini Warning Marker Clam Shell Eye Ring 3D Red/White
WM-CS-E-1E-BW Mini Warning Marker Clam Shell Eye Ring 3D Black/White
WM-CS-E-1E-BY Mini Warning Marker Clam Shell Eye Ring 3D Black/Yellow
