Riken SMVT43 Manual Direction-Control Valve (4-Way 3-Position Valve)
Designed to be mounted on hand and small air pumps for double-acting cylinders.
- Available with 3/8" BSPT (Model number SMVT-43) or 3/8" NPT (Model number SMVT43-NPT) ports.
Specifications
| Model No. | SMVT43 | |
| Hydraulic Symbol Name | Centre Bypass | |
| Max. Operating Pressure (MPa) | 70 | |
| Allowable Back Pressure (MPa) | 1.5 | |
| Max. Flow Rate (L/min) | 3 | |
| Connection Port Size (Rc) | 3/8 | |
| Approx. Weight (kg) | 1.1 |
