BENDING & FABRICATION –
BUSBAR

BUS BAR FABRICATION (MADE IN GERMANY)

PUNCH

Model No. Description
HSBL-2 DigiPunch 160
(containing punch with digital
40800 measuring system, adjustable
work-bench, 2 x 2 m conveyor
system,supports for conveyors)
J HOLE MAKING & BENDING

Model No. HSBL-2 DigiPunch 160
Features Advantages Technical
With the brand-new “DigiPunch 160”, All necessary components except hyd. power
Novopress offers a new class of busbar pack and work cylinder are included in delivery.
punching performance for medium sized Significantly reduced manufacturing cost on For operation only a regular 230VAC power
Businesses. Wherever ordinary manual medium to medium-large output volume. source is needed.
punches are insufficient and CNC-controlled Optimized and speedy workflow through The LCD measuring system works on a
machines are too costly, the new “DigiPunch integrated conveyor system and work-bench. permanent battery basis. Possible hydr. Power
160” is the ideal mid-size solution. It reduces No programming or preparatory work required, Packs: HA 1 - ES, HA 3 and HA 4.
manufacturing time and cost significantly very short set-up times.
compared to manual punches at a very Fast and stepless positioning of busbars in X Length 4.300 mm
modest investment compared to CNC-punches. and Y axis, with 0.5 mm accuracy. Width 550 mm
The very practical configuration with digital Switching from absolute- to chain Height 1.900 mm
metering in X/Y axis and complete conveyors, measurement for fast and easy progressive Weight 170 kg
enables a very efficient and flexible busbar punching. Operating pressure 150 bar
manufacturing. Force 150 KN

POWER PACK

Model No. Description
32530 Power Pack HA 3
33340 Power Pack HA 3 incl. 24 V controls
www.specialisedforce.com.au

Model No.
Features Advantages Technical
Leaders when it comes to switchgear Drive 230 V - 750 W, 4 A
manu facturing. Novopress hydraulic power For heavy duty applications and continuous Weight 26 kg
packs are designed to operate at a low 150 bar production, the HA 3 Power Pack, is the Height 550 mm
over a wide range of applications. professional choice. Length 270 mm
This design combines the clear advantages of With a high performance drive and extended Width 260 mm
increased work safety, and long service life for oil volume, the HA 3 is the ideal power pack Oil capacity 5.5 l
the tool and its attached devices. for demanding busbar production, and/or Operation S 3 S 1=
In addition, these hydraulic power packs are a continuous cable assembly. Available with Safety class IP 55
byword for the high quality associated with all or without 24 V controls for hand operated Hydraulic hose 2.5 m
Novopress products. crimping tools. Operating pressure 150 bar
Oil flow 4.0 l/min.
